- На волне eth... Есть плата, работающая в очень жестких условиях по
ЭМС(не грозы) с кучей выходов и интерфейсов с довольно
параноидальной схемотехникой, причем надежно работающая, значит
разрабы не идиоты. НО, периодически выходит из строя узел
eth(провод до компа пару метров, все в железном кожухе), что и как
выходит из строя неизвестно. Как можно защититься получше в копии и
почему такие странные решения? Andreas(410 знак., Вчера, 14:38 - 22:52, SCH, полностью)
- Я в Ethernet-схемотехнике не силен, но тут явно мне мерещится
какая-то чушь: il-2(165 знак., Вчера, 18:32)
- Сделал защиту двойную, на случай воздушной линии и грозы, отказов
процентов на 90 уменьшилось, схему выложить могу, если ранее не
выкладывал, не помню, но что бы в помещении, странно. Как
отказывают? Физ. уровень греется? У микрочипа прикол есть, земля
только на дно выведена, в LAN8720A, иногда не пропаяна бывает.
Видно по напряжению на токозадающем резисторе. Тактовую проверили?
Резистор возле генератора подозрительно выглядит, может грязь
попала. Светодиоды в разъеме есть? Visitor(8 знак., Вчера, 17:55)
- Между трансом и eth контроллером TVS нужно было поставить "вчера".
И там одной ступенью можно не обойтись. Гуглите аппноты по защите
от горячего подключения к POE инжектору. По моему у микрочипа самая
годная была. - 3m(Вчера, 16:31)
- Поставить внешнюю плату грозозащиты? - PoзoвыйCюcю(Вчера, 15:01, )
- - Что значит "земля всех кварцев висит в воздухе"? Только у
фильтров ПАВ, от кристалла бывает отвод на землю. А вообще
заземлять корпус кварца - моветон. Увеличивает синфазную помеху при
наличии токов помех через земляной полигон и дорожки. И увеличивает
нестабильность частоты, так как ёмкость корпуса на кристалл и
выводы нестабильна. Nikolay_Po(372 знак., Вчера, 14:58)
- Наличие токов через земляной полигон, на котором сидит генератор,
это да, моветон. По хорошему, процэссор должэн сидеть на земляном
острове, один из мысов которого, генератор с кварцэм. Который нужно
заземлить, чтобы экранировать кристалл от внешних воздействий.
Через эту землю не должно течь транзитных токов. У Моторолы были
очень толковые апноты про это. - mse homjak(Вчера, 17:01)
- Хм, обычно в схемах корпус кварца заземляют. Раз разрабы все
сделали правильно, что еще изменить, чтобы не горело? И зачем тогда
конденсаторы между землей разъема и землей контроллера, если через
шасси они гальванически связаны? - Andreas(Вчера, 15:04)
- Ууу... У вас просто не было генератора наносекундных импульсов и
субнаносекундного осциллографа с дифф. щупами чтобы поиграться. Это
они на постоянном токе соединены. Считайте, что везде есть
паразитные индуктивности и никогда нет надёжной, эквипотенциальной
земли. Прилетает помеха - и со стороны платы, куда эта помеха
прилетела, если помеха блокирована, допустим, конденсатором на
землю, земля "подпрыгивает" относительно земли на остальной части
платы. И волна помехи Nikolay_Po(270 знак., Вчера, 15:09)
- Возможно, хотя обычно такое между экраном и земляным проводом
ставят. Так что же можно изменить, вариант POV попробовать,
смотрится симпатично. - Andreas(Вчера, 15:16)
- В схеме Олега,
не хватает я, сослепу, не разглядел разрядника между линиями и землёй. Такая Без разрядников на землю, схема отлично сработает для любых
напряжений ниже пробоя изоляции трансформаторов. Во всех
коммерческих устройствах защиты, разрядники были не между жил пары,
а с каждой жилы на землю. Nikolay_Po(975 знак., Вчера, 16:06 - 16:23)
- Грозы точно нет рядом, все внутри помещения, внутри железного
ящика, поэтому стоит ли ставить разрядники? Может просто TVS,
резисторы маленькие(??) и прорезь зубчатая? - Andreas(Вчера, 16:19)
- Так разрядник со средней точкой на заземление. Это не то? Ставить
двухпиновые (межу линиями и между линиями и заземление) громоздко. - POV(Вчера, 16:08)
- Нужно защищать контакт трансформатора. А то пока до средней точки
импульс напряжения, через индуктивности трансформатора, доберётся,
трансформатор уже может быть пробит. Nikolay_Po(120 знак., Вчера, 16:13)
- Может, платы в ремонт нам отправили, в разъемах трансы не звонятся,
крышки вспучились. Но один случай удивил, трансы в разъеме с обоих
сторон прозваниваются как нужно, осциллом что то не то вижу на TX,
RX, подал меандр с генератора 10 МГц, не проходит, трансы
сплавились, что ли... И, кстати, для теста с генератором питание
платы подавать не нужно. Хотел трансы в разъеме глянуть, не вышло,
там пластик хорошо склеен, только ножевкой, но лень было, выбросил. - Visitor(Вчера, 18:11)
- "есть разрядники с центральным земляным выводом" ну я же ровно про
это и пишу. И картинка такая же. - POV(Вчера, 16:16)
- Не претендуя на гуру, я сделал вот так. Как минимум работает )) POV(44 знак., Вчера, 14:43, картинка)
- Философический вопрос. Если моя программа в ПИКе общается с ПК по
УАРТу посредством моей же программы в ПК, зачем делать скорость из
стандартного ряда? При маленькой рабочей частоте в ПИКе появляется
маленький коэффициент деления (для высоких скоростей обмена), что
чревато некоторой погрешностью. А вот ПК даже 1Мб/с генерит
довольно точно. Или есть ещё подводные камни? - Kpoк(Вчера, 20:28, SCH, полностью)
- Лишний повод срубить копеечку на пропиретарщине! - mse homjak(Вчера, 20:51)
- 1) Не все контроллеры СОМпорта на ПК понимают нестандартные
скорости, 2) Как нестандартную скорость пропихнуть через WinAPI? - Boвa(Вчера, 20:47)
- А если придет нужда у пользователя заменить ПК какой-нибудь "умной
хренью", то у него возникнут проблемы? Он знает заранее об этих
особенностях вашего устройства? Если знает и не имеет возражений,
то пуркуа бы да не па? Вон в автомобильных линиях связи какой
только экзотики, обусловленной исторически, не встречается. :-) - reZident(Вчера, 20:39)
- если будет взаимопонимание на нестандартной скорости, то камней
вроде нет. - =L.A.=(Вчера, 20:32)
- Фигасе... Меня в Телеграме забанили. Ни в группе, ни какой-то
отдельный человек. Получил письмо, что я либо спам рассылал, либо
кому-то свои фото в голом виде демонстрировал... Непонятно, что, но
модераторы Телеграма изучив моё "непонятно что" пришли к выводу,
что меня нужно забанить :))) - st256(Вчера, 17:52, Off, полностью)
- Не знаю как с этим у Телеграмм, но когда на майл.ру за 25 лет китайцы наконец поломали ящик, пришло предупреждение от майла о рассылке спама. У
многих корреспондентов попал в бан. Сменил пароль, порядок,
потихоньку разбанился. - IBAH(Вчера, 21:08)
- Думается до такой низости, как рассылка спама, вы еще не
докатились... Остается второе ;-))) - Гyдвин(Вчера, 17:56)
- Гы-Гы! Проффесорская жопа она такая. - IBAH(Вчера, 20:59)
- Еще еще и третья, и четвертая, и пятая, и ...надцатая причины. Судя
по тому, за что ТС банят здесь, за это же могли забанить и в
телеге, если поступили жалобы сразу от нескольких пользователей. - reZident(Вчера, 19:52)
- "Рассылкой спама" может оказаться нечто немного неожиданное. Лет
пять назад Viber посчитал спамом попытку подключить в группу с
новогодними поздравлениями всех, кто был в моей адресной книге :) Cкpипaч(93 знак., Вчера, 18:15)
- Друзья, посоветуйте какой tft с тачскрином в проекте использовать.
Дюймов на 5-7 или вроде того. По spi и чтоб тач более-менее. Чтоб
можно было и без стилуса. Хотя, наверное, это больше вопрос к
интерфейсу. - vesago(Вчера, 07:41, SCH, полностью)
- Спасибо всем! Есть, смотрю, всякие варианты. И не обязательно в
лоб. - vesago(Вчера, 14:08)
- Nextion? enc(2 знак., Вчера, 09:25, ссылка, ссылка)
- У нас тут 7" TFT захотел заказчик вместо символьного LCD с
клавиатурой. Погромисты сейчас пытаются дисплей от DWIN
приспособить. Они вроде в двух вариантах выпускаются - с емкостным
и с резистивным тачскрином. В емкостной можно пальцем тыкать. Токмо
у выбранного нами UART, а не SPI. Но посмотрите сами. reZident(1 знак., Вчера, 08:35, ссылка)
- Спасибо, знаю Dwin, ну и аналоги. Хорошая штука. Спецсофт и все
такое. Сэкономить бы хотелось. Вот в чем нюанс :) Видал у людей
изделие с таким дисплеем, не Двин имею ввиду - шикарно. Правда
дисплей побольше тоже не 3 копейки. И к нему плата на stm32f7.
Вероятно из-за либы стэшной. Тут уже не факт что дешевле. Ну бог с
ним с дорогими решениями. Я готов на более корявый уи для начала. - vesago(Вчера, 09:21)
- что там хорошая! Двин - отличная штука! Kpoк(2 знак., Вчера, 15:48, картинка, картинка)
- Самое бюджетное что то из массового, планшет на андроиде или esp32
с либой под vga монитор, стандартную ps/2 мышу и клаву либа
поддерживает. - jlm(Вчера, 13:14)
- Я на F429 делал GUI интерфейс с монитором 7 дюймов, но подключение
- RGB (много дорожек, 18 + 3 управлялки). Это самое бюджетное
решение, можно занедорого добавить преобразователь в дифф. сигналы
(hdmi, mipi интерфейс). robinzone(171 знак., Вчера, 12:55)
- Плата на STM32F7 потому, что пикселей много, большие объёмы данных
на интерфейсе. Nikolay_Po(287 знак., Вчера, 09:46)
- Страдальцы, следите за руками. Может сгодится ;) В тырнетах топят
за вражеские VPS... Имею дешевенький VPS в Москве за 78 руб/мес c
пингом от меня 20 мс. Больших проблем с ютубом нет (Таттелеком), но
мелкие таки достают (видимо связано с нагрузкой у прова или
направлением ветра...) - то протухнет на компе, то в TV боксе, то в
планшете. Задолбался тыкать всяческие Bye***. Щас вот решил
поковырять палкой свой VPS - чего он без дела то стоит...
Ковыряться в чОрном терминале Гyдвин(884 знак., 14.10.2024 03:26, Off, картинка, полностью)
- Только снес нафиг Амнезию - на win7 глючит. Поставил OpenVPN на
сервер врукопашную + старенький клиент под win7. А в ведроидах и
win10 "openwpn connect" хорошо дышит... - Гyдвин(Вчера, 19:59)
- Аккурат вчерась, достал полный тормоз бровсека, взял и приладил
Deeprism.. Все завертелось-закружилось-заскакало. Ну, бля, думаю,
ща порнухи науськаю ко сну.. Solo(158 знак., 14.10.2024 10:35)
- Дешевле 99р не нашел, но ограничение 10мбит/с. Поскольку все равно
на работе канал до прова тоже 10мбит, замедления нет, но 1440
максимум было и есть. - Andreas(14.10.2024 09:47)
- Имеется такая схема токового выхода 4-20мА, в чем может быть
причина периодического возбуда под нагрузкой (200 Ом)? Make_Pic(1 знак., 10.10.2024 07:57, SCH, картинка, полностью)
- Если C1 подключить к затвору и +24В, а также увеличить номинал на
2-3 порядка, то схема становится устойчивой. Грубая стабилизация на
одном MOSFET, с точной корректировкой с помощью ОУ. И, как вариант,
eFuse последовательно с R6, на 50...100 мА с напряжением > 150
В De_user(1 знак., 12.10.2024 11:23 - 11:27, картинка)
- Может уважаемый All еще кто то поделится своими схемами токового
выхода? - Make_Pic(12.10.2024 10:10)
- Ничего не понял в приведенной схеме.. Приложу на всяуий случай
простую и рабочую схему, частотник Фуджи, выход аналоговый слева
--> Solo(1 знак., 11.10.2024 13:02, картинка)
- Я стесняюсь спросить, 100ом вместе с емкостью затвора милера, какую
постоянную времени дадут? Не плодите дополнительные сущности в
полосе единичного усиления. - IBAH(10.10.2024 20:23)
- Считаете 100 Ом лишние? - Make_Pic(10.10.2024 21:13)
- смотря в какой ситуёвине. Если есть склонность у возбуду, то да,
мешают, но совсем без резистора тоже "не айс" может быть... Как-то
в одном (не моём) девайсе, и не одном, кстати, рандомно, через
несколько пусков, от десятков, до сотен, вылетал MOSFET, Adept(914 знак., 11.10.2024 23:03)
- А зачем они там нужны? только создают еще один полюс. Посмотрел что
за ОУ SLT1490, полоса ед. усиления 200кГц, я бы и конденсатор
выкинул - IBAH(10.10.2024 21:50)
- Возможно, ОУ "не той системы". Используете LT1490A? - _Илья(10.10.2024 11:57)
- Нет, TPA1862 - Make_Pic(10.10.2024 12:18)
- TPA1862 не подходит. Вход ОУ второго каскада работает практически
около V+, а у TPA1862 допустимое входное синфазное напряжение
(V+)-1,5V. Выше этого напряжения по входу ОУ ведёт себя
непредсказуемо, поэтому и возбуд. Не зря там LT1490A применили, у
него допустимое синфазное по входу до V+. - _Илья(10.10.2024 12:56)
- Поискал высоковольтный опер с R2R входом, поисковик только один
результат дает LT1490, среди 5 вольтовых каждый R2R по входу. - Make_Pic(10.10.2024 21:15)
- Т.е вход не R2R? - Make_Pic(10.10.2024 15:56)
- R2R по выходу. А по входу там только "нижняя рельса" обозначена. reZident(1 знак., 10.10.2024 16:05, картинка)
- Китайский RS8411XF проверил в источнике тока верхнего плеча с p
-канальным ПТ, работает с разницей -1 В по входу от питания. Но на
плате проц имеется, и несколько питаний, вольтодобавку сделал: проц
100 кГц меандр выдает 3.3 В, буфер 74LVC1G14 от 5 В запитан, и
зарядовый насос к питанию +12, вольт 18 стабильно выходит, для ОУ
предостаточно. - Visitor(10.10.2024 20:06)
- От 18-12=6В, откуда такая вольтдобавка от 5вольтового меандра? Я
тоже буфером раскачиваю, но сделал подтяжку к 5В на его входе и
переключил выход проца в режим open drain, так с с гарантией
переключаться будет при любых буферах. - Andreas(10.10.2024 21:58)
- Так он пять удваивает. За вычетом падений на диодах 6 остаётся. - Nikolay_Po(10.10.2024 22:26)
- Он 5 к 12 добавляет за вычетом диодов. При удвоении 5 добавляется к
исходным 5. Откуда добавка больше исходного перепада, если один
каскад добавки? - Andreas(10.10.2024 23:40)
- Через конденсатор, относительно +12 получаем импульсы, диодом
привязываем полочку к +12. Получается, от +12 до +17В пульсирует.
Удваиваем ещё каскадом. В идеале до +22, но в реальности +18. - Nikolay_Po(10.10.2024 23:45)
- Двумя каскадами понятно можно, но ни разу не встречал в реальности,
подождем автора.) - Andreas(10.10.2024 23:46)
- С проца меандр 100 кГц 3.3 в, буфер на 74LVC1G14 с питанием 5 в, RC
цепь с его 51 Ом и 0.1 мкФ на середину BAT54S, анод на + 12, с
катода 10 мкФ на землю. Без нагрузки 20 в, в плате 18 в выходит. - Visitor(11.10.2024 15:06)
- Такая примерно схема? reZident(1 знак., 11.10.2024 16:37, картинка)
- Не понял, откуда 20В без нагрузки? К 12В добавляется 5В минус
падение на диодах. - Andreas(11.10.2024 15:56)
- Если LMC555 запитать напрямую от 12В, то после удвоения ее выхода
те же самые 20В можно получить. Без задействования МК, одногейтовой
логики и трех питаний. - reZident(11.10.2024 15:10)
- Наверное, исторически так сложилось, что 555 не использую:-) А 3
питания мне и так нужны, почему бы и нет. - Visitor(11.10.2024 15:14)
- Ну и зря! Я на ней делал и удвоители напряжения для затворов MOSFET
и инверторы для входа контраста LCD. И "расширители" импульсов для
индикации коротких сигналов. В последнем случае очень не хватает у
555 режима перезапуска, не получается без внешнего транзистора
удлинить ее импульс. - reZident(11.10.2024 15:17)
- Так не удобна, что питание от 3.3.. 5 В не сделать, и одновибратор
на 2х транзисторах удобнее и универсальнее по фронтам запуска,
схему выкладывал, по площади платы одинаково выйдет, хотя в силовых
платах мельчить грех, чипы не менее 1206, мельче не вижу в лупу:-)
А под микроскоп большие платы не лезут. - Visitor(11.10.2024 20:57)
- Привык к 74LVC, одновибраторы и DT формирователи на ней, а ПТ на
мои выходные токи токи на частотах 300.. 400 кГц без драйверов
никак. Когда затык с импортом был, на транзисторах сделал. По
времянке устраивают, потребление больше интегральных, до сих пор
где то в серийных вещах остались, хоть в новые разработки китай
ставлю. До старья руки не доходят. - Visitor(11.10.2024 20:42)
- Тоже применяю 555 по возможности. Использовал её в качестве:
генератора, компаратора, драйвера мосфета, в преобразователе +12 В
в +5/-5 В. Даже как-то дешёвый импульсный источник тока для
светодиодов на ней сделал. Всё работает без проблем уже много лет.
Да и, что сейчас важно, никакие санкции ей не страшны)) - _Илья(11.10.2024 17:17)
- Если уж корректировать 2-й каскад по аналогии как 1-й - то не
хватает резистора. С шунта 250 на "-" ОУ сигнал надо подавать через
резистор 10К. И емкость С1 перенести с шунта на "-" ОУ il-2(221 знак., 10.10.2024 08:15)
- jLT не используется - два прецизионных резистора по 10к - Make_Pic(10.10.2024 07:58)
- Кароч, разработчики, тут этта... Порошок подвезли... mse homjak(1 знак., Вчера, 18:24, Off, картинка, полностью)
- Вопрос из той же оперы. Злополучный PHY. Рекомендуется ставить
последовательные резисторы в линии между контроллером (AT32F407) и
физикой (DM9162IEP), от звона. Есть методика чтобы нормально их
рассчитать? Обязательно ли их ставить при небольшой длине дорожек,
около 2см максимум? Это при наличии резисторов, без них будут ещё
короче. - Pycтaм(Вчера, 11:51, SCH, полностью)
- Как бы не обязательно, не ставлю, а вот по тактированию пришлось. У
СТМ вход до 26 Мег, 50 пришлось триггером делить. На входе 50, на
выходе тоже, пока резистор на вход не добавил. Можно просто дорогу
тактирования шире делать, не 0.25 а 0.4. А для линий не считают
особо, просто Ом 10.. 51 ставят. Для шин сборки резисторов есть,
YC164, например. Места мало занимают. - Visitor(Вчера, 18:48)
- Полчаса рылся в поиске - не смог найти занесённую мной ссылку на
Хабровскую статью по этой теме. Статья была во многом созвучна
этому документу от NSC. Toчкa oпopы(1 знак., Вчера, 14:54, ссылка)
- 1. Рекомендуется. Да. Nikolay_Po(1849 знак., Вчера, 13:10)
- Что мне можно их убрать я уяснил. А есть вариант их рассчитать,
чтоб прям по науке? На будущее, для длинных линий (не тех длинных
линий, которые прям длинные линии) - Pycтaм(Вчера, 12:20)
- В поиске способа расчёта, добивайтесь апериодичности системы,
состоящей из источника тока (выхода) и цепи дорожки и входа. У всех
них есть паразитные параметры, в том числе, и импеданс выхода
относительно земли источника и импеданс между землями чипов. Вот
эта вся вместе система,
должна желательна быть задемфирована резистором так, чтобы всплеск тока
от переключения логического состояния выхода, затухал
апериодически, без колебаний. Nikolay_Po(164 знак., Вчера, 13:15)
- Считается, что нужно согласовывать волновое сопротивление линии с
сопротивлениями на её концах. С той или иной степенью усердия,
соответствующей масштабу проблемы. Зачастую масштаб проблемы такой,
что достаточно нулевого усердия. Ключевые слова "digital line
termination". SciFi(1 знак., Вчера, 13:07, ссылка)
- Что бы прямо по науке, надо узнать волновое сопротивление длиной
линии, вроде бы некоторые трассировщики это умеют, и поставить
такое же сопротивление. Но если умного трассировщика нет, науке
потребуются экспериментальные данные, ставите какое-то
сопротивление, например 50 Ом, хорошим осциллографом смотрите на
звон в цепи, меняете сопротивление, смотрите, и так пока не
получите удовлетворительный звон. - AlexBi(Вчера, 12:57)
- Можно прикинуть на пальцах. reZident(645 знак., Вчера, 12:45)
- Видимо через тау=RC (С - емкость линии и входа пина) - фронт не
должен быть критическим для восприятия на приемной стороне. И там
уж чем больше тем лучше пока еще проходит. - POV(Вчера, 12:25)
- Моё имхо: 2 см фигня, не нужны резисторы. - SciFi(Вчера, 11:58)
- вот так уот POV(1 знак., Вчера, 11:54, ссылка)
- Вот так вот зарядное Bosch bat 6120 "умно" заряжает аккумы --> Solo(2 знак., Вчера, 18:40, Tech, ссылка, картинка)
